Eker Grus
A gravel bike that is swift, smooth and elegant.
The brand new gravel bike
Eker Grus is a versatile bike that is swift, smooth and elegant, weighing in at 9,8 kg. The frame is made by hand, all the way from harvesting the tubes to preparing and joining them into unique pieces of art which nevertheless can withstand long riding in all types of conditions. The Eker Grus bike combines a light and rigid constructed frame, with top of the line components.
Eker Grus
Eker Grus is a gravel bike that is swift, smooth and elegant, weighing in at 9,8 kg. The frame is made by hand, all the way from harvesting the tubes to preparing and joining them into unique pieces of art which nevertheless can withstand long riding in all types of conditions.
Complete your build
Eker Grus is originally fitted with SRAM Rival, 1x11 gear drivetrain, wheels of up to 622 mm (29”), and with a light and durable rigid carbon fork. It can accommodate your fenders and racks of choice, and will without doubt attract envious looks from people in the streets, roads and paths that Eker Varv carries you.
However, you may also want to upgrade your bicycle by choosing your own components or adding accessories. Just place a preliminary order and add your specific comments or requests and we will assist you as best as we can!
Deposit & payment
When you order a bicycle through the form on this page – you are asked to pay a deposit of 500 EUR.
Eker will contact you when final payment shall be made and the bicycle is ready for delivery.
The bike will be shipped when full payment has been received.
Accepted payment methods are by PayPal or invoice.
Delivery Schedule
We will make all our efforts to begin delivering your Eker bicycle as soon as possible. The Estimated time of delivery is only an estimate, is subject to change and we cannot guarantee that we are able to ship the bicycle by the estimated date.
Components & Geometry
Expand to see component details on our different bike builds. Note that due to the global shortage of components, each bike will be adapted and built individually and the choice of components agreed in detail with each customer. The list of components below is therefore for reference only.
| Entry level | Premium level | Insane level | |
|---|---|---|---|
| Frame | Eker Grus 01 with BB86 SRAM GXP bottom bracket, 12x142 thru-axle | ||
| Fork | Gravel carbon fork, 1 1/8"-1 1/5", 12x100 axle, flat mount, internal cabling | ||
| Handlebars | XLC Gravel bar HB-G01 420 mm Black | ZIPP Drop bar Service Course SL 70 XPLR 440 mm | ZIPP Drop bar Service Course SL 70 XPLR 440 mm |
| Stem | XLC Stem ST-M31 Raceby 70 mm +-8° | Stem ZIPP Service Course 70 mm +-6° | Stem ZIPP Service Course SL 70 mm +-6° |
| Saddle | XLC Saddle SA-E16 Everyday 3 | FIZIK Saddle Tundra M5 / Luna X5 | FIZIK Saddle Tundra M3 |
| Seat post | XLC Seatpost SP-O01 350 mm Ø27,2 mm Offset 0 mm | ZIPP Seatpost Service Course 400 mm Ø27,2 mm Offset 20 mm Carbon | DT Swiss Dropper post D 232 ONE Length 400 mm Ø27,2 mm Travel 60 mm |
| Brakes | SRAM Apex 1 | SRAM Rival 1 | SRAM Red AXS eTap |
| Drivetrain | SRAM Apex 1, 1x11 gears | SRAM Rival 1, 1x11 gears | SRAM Red eTap electronic 1x12gears |
| Front chainring | SRAM 42T | SRAM 42T | SRAM XX1 32T |
| Shifter rear | SRAM Apex 1, 1x11 speed | SRAM Rival 1, 1x11 speed | SRAM Red eTap, 1x12 electronic trigger |
| Rear derailleur | SRAM Apex 1, 1x11, long cage | SRAM Rival 1, 1x11, medium cage | SRAM Red eTap, 1x12 speed, carbon cage |
| Cassette | SRAM PG-1130 11-36T | SRAM PG-1130 11-36T | SRAM XG-1290 12 SPEED 10-28T eTap |
| Chain | SRAM PC-1110 | SRAM PC-1170 | SRAM PC-RED 22 |
| Crankset | SRAM Apex 1 GXP 42T 172,5 MM | SRAM Rival 1 GXP, 42T, 172,5 mm | SRAM Red 1 AXS, 40T, 172,5 mm |
| Wheels | DT SWISS Wheel G 1800 Spline DB 25 700c | DT SWISS Wheel GR 1600 Spline DB 25 700c | ZIPP Wheel 303 S 700c carbon Tubeless |
| Tires | SCHWALBE G-One Bite, 40-622 | SCHWALBE G-One Bite, 40-622 | SCHWALBE G-One Bite, 40-622 |
| Weight: 9–11 kg depending on components as well as bamboo density (but remember – the higher the weight, the more carbon dioxide you remove from the atmosphere…) | |||
| Size | Small | Medium | Large | X Large |
|---|---|---|---|---|
| Seat tube length (st) | 510 | 540 | 560 | 580 |
| Top tube length (tt) | 525 | 542 | 558 | 572 |
| Head tube length (ht) | 104 | 140 | 160 | 175 |
| Head tube angle (ha) | 72° | 72° | 72° | 72° |
| Seat tube angle (sa) | 74,0° | 74,0° | 74,0° | 74,0° |
| BB drop (drop) | 65 | 65 | 65 | 65 |
| BB height (height) | 288 | 288 | 288 | 288 |
| Chainstay length (cs) | 430 | 430 | 430 | 430 |
| Wheel base | 1000 | 1018 | 1035 | 1050 |
| Stack | 523 | 557 | 576 | 591 |
| Reach | 374 | 381 | 392 | 402 |
| Stem length | 100 | 100 | 110 | 110 |
| Handlebar width | 400 | 420 | 420 | 440 |
| Crank length | 170 | 172,5 | 172,5 | 175 |
| Seat post diameter | 27,2 | |||
| Seat post length | 400 | 400 | 400 | 400 |
| Wheel radius incl. tyres | 700c (ISO 622) | |||
| Stand over height | 781 | 812 | 834 | 850 |
| Rear dropout | 12x142 | |||
| Fork rake/offset | 50 | |||
| Trail | 62 | |||
| Fork length, full | 390 | |||
| Gears | 1x11 | 1x11 | 1x11 | 1x12 |
| Tyre size, mm | 40-622 | |||
Order your Grus
Order today and we will have your Eker Grus shipped within 4 weeks for delivery before 2023-07-07.
